Ocean: 3D Gesture Sensor for Raspberry Pi, Arduino and STM32.

CQRPAJ7620U2 is a 3D gesture recognition sensor with integrated PAJ7620U2 chip, PAJ7620U2 integrates the gesture recognition function and the universal I2C interface into one chip. It can recognize 9 gestures, including move up, move down, move left, move right, move forward, move backward, rotate clockwise, rotate counterclockwise, and waveform. These gesture information can be easily accessed through the I2C bus. PAJ7620U2 also provides built-in proximity detection for sensing objects approaching or leaving. PAJ7620U2 has great flexibility in power saving institutions.

Compare with solutions like APDS-9960, this module is faster, more accurate, while recognising more gestures with higher anti-interference capability. It suits for low power applications such as smart home, robot interaction, etc.

Onboard voltage translator, compatible with 3.3V/5V operating voltage, Compatible with Raspberry Pi, Arduino, STM32 and other motherboards.

Wiki: http://www.cqrobot.wiki/index.php/3D_Gesture_Sensor_SKU:_CQRPAJ7620U2

APPLICATIONS

• Robot Interaction
• Smart Home, Office and Education
• Toys, Motion Sense Gaming Devices

SPECIFICATION

3D Gesture Sensor Specifications

• Model: CQRPAJ7620U2
• Operating Voltage: 3.3V/5V
• Communication Interface: I2C
• Recognition Distance: 5cm to 15cm
• Supported Gestures: up, down, left, right, forward, backward, clockwise, anticlockwise, shake.
• Recognition Rate: 240Hz
• Recognition Angle: 60 Degree (diagonal)
• Ambient Light Immunity: Less Than 100k Lux
• Dimensions: 23.14mm * 27.76mm
• Mounting Hole Size: 3.0mm

Ocean Interface Cable Specifications

• Cable specifications: 22AWG
• Material: Silicone
• Withstand Voltage: Less Than 50V
• Withstand Current: Less Than 1000MA
• Length: 21cm
• Line Sequence: Black-Negative Power Supply, Red-Positive Power Supply, Green-SDA, Blue-SDA, Yellow-INT.

SHIPPING LIST

1 * 3D Gesture Recognition Sensor (PAJ7620U2)

1 * Ocean Interface JST 5-Pin Cable
