USB to RS232 Female DB9 Serial Port Adapter Cable

USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
New
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
USB to RS232 Female DB9 Serial Port Adapter Cable
$9.99
Ex Tax: $9.99
3 or more $9.39
20 or more $8.99
50 or more $8.33
  • Stock: In Stock
  • Brand: Pzsmocn
  • Model: VenelDT-5002Bgb
  • Weight: 205.00g
  • SKU: VenelDT-5002Bgb
  • ASIN: B074NZ5FPW

With the continuous development of PC industry, USB interface is gradually replacing the old industrial low-speed PC interface, which makes DB9 serial connection more difficult to access the new computer system. But in the actual industrial environment, there are still many important devices that need to use RS232 interface.

The USB to RS232 serial port product is the standard product of enhanced universal asynchronous transceiver transmission. The USB interface conforms to the full speed USB 2.0 specification, supports the full speed data transmission rate, and the serial port conforms to the standard RS232 interface. It provides us with a plug-and-play RS232 serial port, connects the DB9 serial port to the computer through USB interface, and easily uses the serial port adapter. It can be used for RS232 serial equipment such as cash register, LED display screen, numerical control machine tool, industrial instrument, bar code printer, etc. to realize the connection between computer and various serial equipment.

Note: For more technical parameters and driver downloads, please refer to the user manual provided by Pzsmocn Wiki, SKU: PZSRS232-A.

Wiki:http://www.pzsmocn.wiki/index.php/USB_to_RS232_Serial_Port_Adapter_Cable_SKU:_PZSRS232-A

SPECIFICATIONS

  • Operating temperature: - 40 celsius degree to 85 celsius degree
  • Working Voltage: 5V
  • Working Current: 200mA
  • Chipset: PL2303GT
  • Baud Rate: 300bps to 1000000bps
  • Circuit Integrated ESD Protection: ± 15KV IEC1000-4-2 air gap discharge; ± 8KV IEC1000-4-2 contact discharge
  • Tensile Test: 20 KG
  • Material: epoxy glass fiber double-sided board
  • Wire Material: aluminum foil and 80B tinned copper
  • Color: transparent green
  • Cable Length: 1.8m
  • Supported Systems: Android SDK, Linux, Mac, Windows

PACKAGE LIST

USB 2.0 to DB9 RS232 Conversion Cable (1.8M) * 1

CD-ROM Software Driver * 1
